呼吸器 27. 肺胞の血管注入 1.
ヒト、肺動脈から朱を注入、フォルマリン固定、セロイヂン包埋、
x 200.------------------------------------------------
これは肺胞中隔の中の毛細血管網を可視化する目的で肺動脈から朱を注入した
標本である。この標本は特に厚く100μで切ってあるので、肺胞中隔の中の毛細-
血管網が立体的に観察される。-----------------------------------------
Respiratory system 27. Infusion
of alveolar capillary mesh work 1.
Human, infusion with cinnabar
from pulmonary artery, embedding with
celloidin, x 400.-----------------------------------------------
The capillary meshwork in the alveolar septum is visualized by
cinnabar
infusion. Because of the 100μ thickness, 3 dimensional configuration
of
alveoli is evidently seen. ---------------------------------------
