呼吸器 28. 肺胞の血管注入 2.
ヒト、朱を肺動脈より注入、セロイディン包埋、x 400.
これは肺動脈から朱を注入して肺胞中隔の中の毛細血管網を可視化した標本で
ある。この多数の網の目の中に細網繊維と弾性繊維が存在し、それらが肺胞の-
形を維持している。---------------------------------------------------
Respiratory system 28. Infusion
of alveolar capillary mesh work 2.
Human, infusion with cinnabar
from pulmonary artery, embedding with
celloidin, x 400.-----------------------------------------------
To visualize the alveolar capillary mesh work, infusion with cinnabar
from -
pulmonary artery is performed. In these meshes there should be
reticular
fibers and also elastic fibers that serve as structural skeleton
to keep the
form of alveoli. --------------------------------------------------
