腎臓13. 腎迷路の尿細管 3.
ヒト、ブアン液で固定、パラフィン包埋、M-G染色、x 600.
「腎臓 7」と同じ標本。この図には集合管の始まりの部分である結合部(中央左)
と主部(結合部を取り囲む5個の断面)と介在部(右上の隅)が示されている。-
結合部は淡染する透明な細胞質の中に小円形の核を持った単層立方上皮細胞から
なる。細胞境界が明瞭であることがこの管の特徴である。主部の上皮細胞の特徴-
は「腎臓 10」に記載した通りであるが、この図では特に刷子縁が明瞭に認められ
る。個々の尿細管を取り巻く緑色に染まった基底膜及び尿細管の間の毛細血管も-
明らかである。---------------------------------------------------------------------------------
Kidney
11. Urinary tubules in renal labyrinth 3.
Human, fixation with Bouin’s fluid, embedding with paraffin,M-G stain, x 600.
The
same specimen as “Kidney 5”. In this figure a transverse section of the-------------
beginning
portion of the collecting tubule(middle left), 5 sections of the proximal------
convolutions
and a section of distal convolutions(upper right corner) are shown.-------
The collecting tubule is the beginning portion of excretory duct of kidney and consists
of small
clear cuboidal cells, with distinct cell border. The characteristics of the----------
proximal
convolutions are described in “Kidney 10”, but in this figure the brush--------
border
is especially conspicuous. The basement membrane surrounding each tubule-
and
capillary meshwork between tubules are also clearly distinguished.------------------
