腎臓 14. 腎迷路と腎小体.
ヒト、ブアン液で固定、パラフィン包埋、M-G染色、x 200.
これは死後約3時間の死体から得られた標本で、細胞・組織の保存が非常によい。---
しかし切片の厚さが、「腎臓 7~13」の約2倍、約7μmであるので、細胞の染ま------
りが濃くて、全体としては理解しやすいが、他方、細胞の微細構造はやや分かり難----
い。この図は腎迷路の一部で、1個の腎小体とそれを取り巻く多数の尿細管の主部、-
数個の介在部と1個の集合管の断面が見られ、これらの構造物の間は毛細血管で埋----
め尽くされている。この腎小体には左側に血管極、右側に尿管極が備わっている。----
この腎小体の拡大が「腎臓 15,16」に示される。これ以後「腎臓22」まで、これと----
同じ標本。--------------------------------------------------------------------------------------------
Kidney
14. Renal labyrinth and renal corpuscle.
Human, fixation with Bouin’s fluid, embedding with paraffin, M-G stain, x 200.
This
specimen was obtained from a male corpse, 3 hours post mortem, and cells---------
and
tissues were very well preserved. Because of thickness of this preparation, ca.-----
7μm, cells and tissues are stained deep and
easy to identify but their fine structure----
is
less clear than that in “Kidney 57~ 13”.This figure shows a portion of the
renal-------
labyrinth,
containing one renal corpuscle and numerous sections of renal tubules, i.e.-
proximal
and distal convolutions and one collecting tubule. This renal corpuscle---------
provides
the vascular pole at left and the urinary pole at right. Higher magnifications--
of
this are shown in “Kidney 15 and 16”. “Kidney 17 ~ 22” are the same specimen-------
as “Kidney
14”.--------------------------------------------------------------------------------------------
