腎臓 16. 腎小体の血管極 2.
ヒト、ブアン液で固定、パラフィン包、M-G染色、x 500.
「腎臓15」の拡大。右上から腎小体に入ってくる血管が輸入細動脈であり、その----
流入部の左側を上方に出ていくのが輸出細動脈である。両者に挟まれたV字形の--
くぼみを満たしている紫色に濃染した小さい核がグールマーティ細胞の核である。
その上方に1個の管の断面が接しており、その下方の壁では上皮細胞の核の密度が、
上方の壁に比べて、著しく大である。この部分を特に緻密斑という。この管の断面
の左に3個の断面が接しているが、これらは介在部である。輸入細動脈の壁には明
るい透明な細胞体の中に円形の核を持つ細胞が見られる。これが傍糸球体細胞であ
る。この標本は少し厚いので、糸球体における「足細胞」と血管内皮細胞の区別は
困難である。しかし画面の下縁の中央やや左にある2個の大きい核は「足細胞」の
核である。ボウマン嚢の内面を被う上皮細胞の核は、左側に2個、右側に1個に認
められる。----------------------------------------------------------------------------------------
Kidney
16. Vascular pole of a renal corpuscle 2.
Human, fixation with Bouin’s fluid, embedding with paraffin,M-G stain, x 500.
Higher
magnification of “Kidney 15”. From upper right an afferent arteriole comes----
into the renal corpuscle and an efferent arteriole goes out from the left to the ―――
former.In
the V shaped hollow between the afferent and efferent arterioles there-----
are numerous
small nuclei, i.e. nuclei of Goormaghtigh. Above them a section of ------
distal
convolutions, whose lower wall has more numerous and tightly arranged nuclei
than
its upper wall and is named as macula densa. Left to this 3 sections of distal-------
convolutions
are noted. Since this preparation is somewhat thick, nuclei of-podocytes
and
that of capillary endotheliar cells are difficult to identify, but--2 large nuclei at ----
middle
left of lower edge of this field are certainly that of--podocytes.
Nuclei of ---------
covering
epithelium of the Bowman’s capsule are visible-
one at right side and 2 at----
left
side.---------------------------------------------------------------------------------------------------
