腎臓 21. 髄放線の縦断.
ヒト、ブアン液で固定、パラフィン包埋、M-G染色、x 500.
これは髄放線の縦断面で、中央を横に走るのが集合管、その左下がヘンレのループ
の太い部分、集合管の上下に並んでいるのが主部の直部である。集合管の上皮細胞
が染料に染まらない透明な胞体の中に円形の核を持ち、細胞境界が明瞭な単層立方
上皮で縁取りされていることがよくわかる。主部の直部は曲部よりやや細いが、そ
の細胞の特質は曲部の細胞と同じである。ヘンレのループの太い部分の細胞は、介
在部(遠位曲尿細管)のそれに似ているが、細胞の丈が低くて、核がしばしば内腔
に隆起している。―――――――――――――――――――――――――――――
Kidney
21. Longitudinal section of medullary ray.
Human, fixation with Bouin’s fluid, embedding with paraffin,M-G stain, x 500.
In
the middle one collecting tubule runs horizontally, and lower left to this one thick----
portion of loop of Henle and upper and lower to them two straight portions of proximal
convolutions
run parallel to each other. It is clear that constituting cells of the collecting
tubule,
simple cuboidal in shape, provide pale colorless cytoplasm and very distinct------
cell
border. The straight portion of the proximal convolutions is somewhat smaller
in----
diameter
than their convoluted portion and consists of the almost identical cells of the---
convoluted portion. The thick portion of the loop of Henle consists of cells being alike to
the cells of the distal convolutions but much less tall so that the nuclei protrude into the
lumen.-------------------------------------------------------------------------------------------------------
