腎臓 24. 髄質の外帯
3.
ヒト、ブアン液で固定、パラフィン包埋、M-G染色、x 400. (厚さ3μmの標本)
これは「腎臓 7~13」と同じ厚さ3μmの標本であり、尿細管各部の詳細がよく観察
できる。画面の右下約1/3の範囲を占める9個の断面は主部の直部で、上皮細胞は赤
く濃染し、細胞の自由表面に著明な刷子縁を備えている。これらに囲まれて1個のヘ
ンレのループの太い部分が見られる。画面の左上約2/3の範囲に、3個の太い管が見
られるが、これらは集合管であり、細胞境界が明瞭な、胞体の明るい上皮細胞で縁取
られている。これらのうちの右上の管のすぐ右下に隣接する1個に細い管がヘンレの
ループの細い部分で、極めて扁平な細胞体は光学顕微鏡では確認することが困難であ
り、核だけが管腔に突出して見える。これら以外の管はヘンレのループの太い部分で
あり、やや淡く赤く染まった丈の低い上皮細胞で縁取られ、外径のわりに内腔が広い。
これらの管の周囲は緑色に染まった結合組織で埋められており、その中には多数の毛
細血管が存在する。-------------------------------------------------------------------------------
Kidney
24. Outer zone of renal medulla 3.
Human, fixation with Bouin’s fluid, embedding with paraffin, M-G stain, x 400.
This
is the same section of “Kidney 7~13” of 3μm thick, so that the fine structures-----
of each
portion of the urinary tubules are well distinguishable. In about 1/3 of lower----
right
of this field, there are 9 sections of the straight portion of the proximal
tubule,----
consisting
of tall and deeply reddish stained epitheliar cells with conspicuous brush------
border
at free surface. Surrounding by them one thick portion of loop of Henle,---------
constituted
with less deeply reddish stained low epitheliar cells. In about 2/3 of upper---
left
of this field 3 big collecting tubules are seen. They consists of cuboidal
epithiliar----
cells
with evident cell border. Lower right to the uppermost of them, there is a thin-----
portion
of loop of Henle, being constituted with very flattened epitheliar cells, so
that--
only
nuclei protruding into the lumen are recognized. Others are almost the thick-------
portions
of thick portion of loop of Henle, whose epitheliar cells are low cuboidal and--
less
deeply reddish stained. They are smaller in outer diameter than the straight-------
portion
of the proximal tubules but larger in caliber.--------------------------------------------
