子宮8.ラセン動脈.
ヒト、月経周期第22日、ブアン液で固定、パラフィン包埋、H-E染色、x 120.
これは月経周期第22日の子宮内膜の機能層の深部に見られるラセン動脈である。
画面の右約2/3では内膜の支質の細胞間に液体が貯留して浮腫状になっている。
左下から右上に向かって、曲がりくねって走っているのがラセン動脈である。画-
面の左約1/3では、腺腔が拡大して盛んな分泌を行っている子宮腺が見られる。
Uterus
8. The spiral artery.
Human, on the 22nd day of menstrual cycle, fixation with Bouin’s fluid, embedding
with
paraffin, H-E stain, x120.------------------------------------------------------------------
This is a spiral artery found in the deep layer of the endometrium, running tortuous
from
left bottom to right top. In the right 2/3 of the field, spaces among the stromal-
cells
are filled with exudate, looking as edema. The left 1/3 of the field is
occupied---
by
uterine glands with wide lumen indicating active secretion.---------------------------
